LS MCB

Categories: ,

Rated Current, (A) : 6, 10, …….. 63
Type : B, C & D
No. of Poles : 1, 2, 3
Type B (For General / Lighting): ≥ 3In ≤ 5 In
Type C (For General): ≥5 In ≤10 In
Type D (For General / Motor): ≥10 In ≤ 20 In

* SIRIM – IEC 60898

Download Catalogue
Catalogue 1

BREAKING CAPACITY : 6KA

Model
Type – B		 Model
Type – C		 Model
Type – D		 Current Rating (Ampere) No.of Pole Quantity Per Box
BKNB611 BKNB611 BKNB611 6, 10, 16, 20, 32 1 12
BKNB6140 BKNB6140 BKNB6140 40, 50, 63
BKNB621 BKNB621 BKNB621 6, 10, 16, 20, 32 2 6
BKNB6240 BKNB6240 BKNB6240 40, 50, 63
BKNB631 BKNB631 BKNB631 6, 10, 16, 20, 32 3 4
BKNB6340 BKNB6340 BKNB6340 40, 50, 63
Optional: Side Mount Auxiliary Contact AX For BKN MCB

BREAKING CAPACITY : 10KA

Model
Type – C		 Current Rating (Ampere) No.of Pole Quantity Per Box
BKN-b C1011 6, 10, 16, 20, 32 1 12
BKN-b C10140 40, 50, 63
BKN-b C1021 6, 10, 16, 20, 32 2 6
BKN-b C10240 40, 50, 63
BKN-b C1031 6, 10, 16, 20, 32 3 4
BKN-b C10340 40, 50, 63
* MCB 10kA Type-B and Type-D available upon request.
